Product Advantages
-
Excellent high and low temperature performance
-
Meets charging needs from -30℃ to 60℃
-
Also suits discharging from -40℃ to 60℃
Main Product Parameters
-
18650F8T
2500mAh
-
18650F2T
2000mAh
-
-
Nominal Capacity
2500mAh
-
Nominal Voltage
3.6V
-
Internal Impedance
≤25mΩ
-
Max. Continuous Charge Current
1C(2500mA)
-
Max. Continuous Discharge Current
3C(7500mA)
-
Mass Energy Density
200 Wh/kg
-
Volume Energy Density
529 Wh/L
-
Operating temperature
Charging operating temperature: -30℃ to 50℃
Discharging operating temperature: -40℃ to 60℃
Low-temperature discharging (-40℃)
With 0.5A discharge capacity ≥ 2000mAh (4.2-2.75V) -
RT Cycle Life
500 Cycle ≥ 70%(0.5C/1.0C）
-
-
-
Nominal Capacity
2000mAh
-
Nominal Voltage
3.65V
-
Internal Impedance
≤40mΩ
-
Max. Continuous Charge Current
1C(2000mA)
-
Max. Continuous Discharge Current
3C(6000mA)
-
Mass Energy Density
168 Wh/kg
-
Volume Energy Density
427 Wh/L
-
Operating temperature
Charging operating temperature: -30℃ to 60℃
Discharging operating temperature: -40℃ to 60℃
Low-temperature discharging (-40℃)
With 0.4A discharge capacity ≥ 1000mAh (4.2-2.0V) -
RT Cycle Life
400 Cycle ≥ 60%(1.0C/1.5C）
-
Service Support
Rapid Response After-sales Service
With a dedicated after-sales service team providing 7X24 technical support, users can receive a rapid response in a short period of time, effectively shortening the maintenance cycle.
Professional Team Support
CHAM has been focus on new energy core technology for 20 years, providing customized products and services to customers with its professional pre-sales and R&D teams.
Convenient Service Channel
Extensive sales networks, factories, and after-sales service centers have been strategically deployed in various locations such as Shenzhen, Dongguan, Sichuan, Jiangsu, Indonesia, and Germany.
Customized Design Services
Our professional R&D team focuses on meeting the individual needs of our clients, tailored to create efficient and stable battery solutions that facilitate the successful implementation of projects.
